84-17-3

DIENESTROL

Product Name DIENESTROL

CAS84-17-3

MFC18H18O2

MW266.33

More

  • 84-17-3_ms
    Mass

    MS2004-02324WA
    4,4'-(diethylideneethylene)diphenol
    C18H18O2            (Mass of molecular ion:    266)


       Source Temperature: 250 °C
       Sample Temperature:  20 °C
       Direct, 70 eV


          18.0       1.8
          39.0       2.0
          43.0       1.0
          51.0       1.7
          55.0       2.7
          63.0       1.6
          65.0       2.7
          76.0       1.3
          77.0       8.3
          78.0       1.5
          79.0       2.7
          88.0       1.0
          89.0       2.9
          91.0       4.5
          94.0       1.8
          94.5       1.3
          95.0       1.0
          97.0       1.2
         101.0       2.5
         102.0       1.4
         103.0       5.2
         104.0       1.3
         105.0       4.5
         107.0      16.0
         108.0       1.5
         109.0       1.9
         115.0       8.4
         116.0       2.9
         117.0       1.6
         118.0       4.0
         119.0       2.6
         121.0      24.9
         122.0       2.3
         125.0       1.5
         125.5       1.0
         127.0       4.9
         128.0       4.6
         129.0       2.6
         131.0       6.4
         132.0       2.1
         133.0       7.9
         134.0       1.2
         139.0       1.5
         141.0       1.6
         143.0       1.4
         144.0       4.3
         145.0      22.1
         146.0       2.9
         151.0       1.4
         152.0       4.5
         153.0       2.2
         155.0       1.4
         157.0       9.0
         158.0       6.7
         159.0       4.7
         160.0       1.1
         165.0       4.5
         166.0       1.2
         171.0       2.9
         172.0       6.5
         173.0       8.0
         174.0       1.1
         176.0       1.3
         177.0       1.2
         178.0       2.6
         179.0       1.5
         181.0       4.8
         182.0       1.2
         189.0       3.2
         190.0       1.9
         191.0       2.6
         194.0       2.7
         195.0       2.5
         201.0       2.0
         202.0       2.8
         203.0       1.9
         205.0       2.4
         206.0       1.1
         207.0       4.5
         208.0       3.4
         209.0       4.1
         210.0      14.4
         211.0       2.9
         215.0       2.7
         218.0       5.1
         219.0       5.4
         220.0       1.9
         221.0       2.3
         222.0       1.9
         223.0       5.4
         224.0       1.5
         231.0       2.2
         232.0       1.6
         233.0       4.8
         234.0       4.2
         235.0       4.1
         236.0      13.3
         237.0      35.3
         238.0       7.6
         239.0       3.6
         247.0       1.4
         248.0       1.0
         249.0       7.4
         250.0       6.8
         251.0      50.4
         252.0       9.6
         253.0       1.4
         264.0       2.5
         265.0       7.5
         266.0     100.0
         267.0      19.6
         268.0       2.3
         282.0       1.2


400 MHz in CDCl3

  • 84-17-3_1hnmr

    1H NMR 399.65 MHz
    C18 H18 O2 0.037 g : 0.5 ml DMSO-d6
    4,4'-(diethylideneethylene)diphenol
    ChemicalStructure
        Assign.     Shift(ppm)
    A 7.458 B 7.305 C 5.779 D 1.974

         Hz     ppm     Int.


       2985.60   7.471    592
       2981.08   7.460     94
       2977.17   7.450    783
       2923.34   7.315    776
       2914.79   7.294    630
       2319.82   5.805     70
       2316.89   5.798     38
       2313.11   5.788    251
       2309.57   5.779     47
       2306.40   5.772    246
       2302.49   5.762     36
       2301.51   5.759     36
       2299.56   5.754     68
       2299.32   5.754     68
        800.42   2.003     34
        799.93   2.002     37
        792.36   1.983   1000
        785.77   1.967    946


in CDCl3

in DMSO-d6

  • 84-17-3_13cnmr_2

  • 84-17-3_13cnmr

KBr disc

  • 84-17-3_ir1_2

nujol mull

  • 84-17-3_ir2
