Cyclohexanol

Product Name Cyclohexanol

CAS108-93-0

MFC6H12O

MW100.16

¹³CNMR

Mass

MS-NW-5520
cyclohexanol
C6H12O              (Mass of molecular ion:    100)

   Source Temperature: 260 °C
   Sample Temperature: 190 °C
   Reservoir, 75 eV

      15.0       1.4
      18.0       1.7
      26.0       1.3
      27.0      11.4
      28.0       3.5
      29.0      10.1
      31.0       5.9
      38.0       1.0
      39.0      11.4
      40.0       2.2
      41.0      22.7
      42.0       7.4
      43.0       6.9
      44.0      24.0
      45.0       4.0
      50.0       1.1
      51.0       1.6
      53.0       4.1
      54.0      14.8
      55.0       8.1
      56.0      13.2
      57.0     100.0
      58.0       8.7
      67.0      26.5
      68.0       1.8
      69.0       1.8
      70.0       1.2
      71.0      13.2
      72.0       7.0
      79.0       1.7
      81.0       5.4
      82.0      46.1
      83.0       4.1
      85.0       1.0
      99.0       1.4
     100.0       3.3

90 MHz in CDCl3

400 MHz in CDCl3

¹H NMR	89.56 MHz
C₆ H₁₂ O	10.3 mol% in CDCl₃
cyclohexanol

    Assign.     Shift(ppm)

      A             3.58
      B             2.63
      C          1.04 to 2.04

     400MHZ : HSP-40-238

     Hz     ppm     Int.

    331.00   3.696     30
    326.38   3.645     45
    325.44   3.634     49
    324.50   3.624     48
    321.63   3.592     68
    319.44   3.567     48
    318.63   3.558     52
    317.31   3.543     66
    315.94   3.528     50
    313.75   3.504     40
    313.00   3.495     37
    312.00   3.484     46
    235.56   2.631   1000
    179.50   2.005     37
    178.25   1.991     48
    174.50   1.949     84
    172.63   1.928    105
    170.50   1.904    142
    169.56   1.894    151
    168.69   1.884    145
    167.38   1.869    152
    166.50   1.860    147
    165.81   1.852    148
    163.25   1.823    138
    161.00   1.798    163
    160.06   1.788    158
    158.63   1.772    183
    156.69   1.750    156
    155.06   1.732    181
    154.06   1.721    181
    148.44   1.658     87
    147.38   1.646     83
    145.94   1.630     83
    145.81   1.629     83
    144.81   1.617     83
    143.31   1.601     94
    142.63   1.593     99
    141.63   1.582    100
    140.63   1.571     97
    140.06   1.564     98
    138.75   1.550    101
    137.63   1.537     99
    134.13   1.498     81
    131.19   1.465     92
    130.88   1.462     93
    130.38   1.456     95
    129.69   1.449     91
    129.56   1.447     91
    128.88   1.440     91
    128.75   1.438     91
    126.69   1.415     90
    126.25   1.410     90
    121.75   1.360    154
    118.81   1.327    178
    114.38   1.278    293
    113.31   1.266    334
    110.75   1.237    298
    109.13   1.219    263
    107.38   1.199    202
    105.75   1.181    223
    105.00   1.173    222
     99.81   1.115     67
     99.44   1.111     66

¹H NMR	399.65 MHz
C₆ H₁₂ O	0.05 ml : 0.5 ml CDCl₃
cyclohexanol

    Assign.     Shift(ppm)

      A             3.578
      B             2.84
      C             1.882
      D             1.728
      E             1.542
      F          1.30 to 1.22
      G             1.16

     Hz     ppm     Int.

   1443.48   3.612     49
   1439.21   3.602     79
   1434.08   3.589    131
   1429.93   3.578    156
   1425.54   3.567    129
   1422.49   3.560     76
   1420.53   3.555     85
   1416.50   3.545     39
   1134.40   2.839   1000
    761.60   1.906    131
    756.71   1.894    266
    753.66   1.886    272
    752.56   1.884    276
    749.88   1.877    228
    748.66   1.874    226
    743.53   1.861    158
    700.93   1.754    120
    697.39   1.746    176
    692.87   1.734    223
    691.89   1.732    233
    688.84   1.724    327
    685.18   1.715    235
    683.96   1.712    217
    679.69   1.701     92
    673.95   1.687     45
    672.36   1.683     36
    625.37   1.565     95
    623.54   1.561    107
    622.44   1.558    126
    621.34   1.555    112
    619.38   1.550    100
    617.19   1.545     82
    615.84   1.541     97
    614.38   1.538    101
    613.04   1.534    102
    610.35   1.528    132
    608.15   1.522    102
    606.93   1.519    109
    603.39   1.510     42
    602.42   1.508     40
    529.05   1.324     61
    525.76   1.316     62
    521.48   1.305     78
    517.46   1.295    162
    512.94   1.284    254
    511.84   1.281    267
    508.06   1.272    319
    504.64   1.263    539
    502.69   1.258    527
    496.95   1.244    289
    493.04   1.234    408
    483.76   1.211    111
    482.18   1.207    110
    479.25   1.200    100
    475.83   1.191     86
    474.00   1.187     77
    470.21   1.177     84
    466.80   1.169    105
    464.23   1.162    103
    458.62   1.148     79
    455.20   1.139     81
    451.66   1.131     64
    447.27   1.120     32
    443.73   1.111     30

in CDCl3

CCl4 solution

liquid film

4880 A,200 M,liquid
