ABB YPH107A 3ASD573001A9

Choose Moore Automation Limited - Biggest supplier in China

Packing & Delivery
1)100% full New! - Original Factory Seal !
2)Warranty: 12 months!
3)Package: Original packing with cartons.
4)Delivery time: Shipped in 3 days after payment

S800 I/O Station
A S800 I/O Station can consist of a base cluster and up to 7 additional I/O clusters. The base cluster consists of a Fieldbus Communication Interface and up to 12 I/O modules. I/O cluster 1 to 7 consist of an Optical ModuleBus modem and up to 12 I/O modules. A S800 I/O Station can have a maximum of 24 I/O modules. I/O cluster 1 to 7 is connected to the FCI module through an optical expansion of the ModuleBus.

ModuleBus
The Fieldbus Communication Interface module communicates with its I/O modules over the ModuleBus. The ModuleBus can support up to 8 clusters, one base cluster and up to 7 I/O clusters. The base cluster consists of a communication interface module and I/O modules. An I/O cluster consists of an Optical ModuleBus modem and I/O modules. The Optical ModuleBus modems are connected via optical cables to an optional ModuleBus Optical port module on the communication interface module. The maximum length of the Optical ModuleBus expansion is dependent of the number of Optical ModuleBus modems. The maximum length between two clusters is 15 m (50 ft.) with plastic fiber and 200 m (667 ft.) with glass fiber. Factory made optical cables plastic fiber) are available in lengths of 1.5, 5 and 15 m (5, 16 or 49 ft.). The Optical ModuleBus expansion can be build up in two ways, a ring or a duplex communication.
