银白浆
Silver-White Paste
特性
该系列非浮型铝银浆,具有非凡的遮盖力,优 良的白度和中等的闪亮特性 , 能为用户提供满 意的着色力和优雅的金属效果 。
Properties
This series of non-leafing aluminium paste has extraordinary hiding power,good whiteness,and medium lightness,providing strong tinting strength and elegant metal effect.
典型应用
适用于溶剂系统 。
广泛应用于普通工业漆、卷材涂料、船舶漆、 防锈涂料等 。
Typical Application
For solvent system.
Widely applied in general industrial coatings, coilcoatings,marine paint,anti-corrosion paint,etc.
型 号 Grade | 固 含 量 Nonvolatile content %(±2) | 溶剂类别 Solvent | 湿法筛网 通 过 率 Screen analysis <45μm(≥%) | 平 均 粒 径 Average partcle size (μm) | 比 重 Specific gravity (g/cm³) | 铝片形貌 Particle Shape | 浮 / 非 浮 Leafing Non-leafing |
ZX3100 | 65 | MS/SN | 99.0 | 15 | 1.5 | C | 非浮NL |
ZX3016 | 65 | MS/SN | 99.0 | 6 | 1.4 | C | 非浮NL |
ZX3004B | 65 | MS/SN | 99.0 | 3.5 | 1.4 | C | 非浮NL |
ZX5075 | 65 | MS/SN | 99.0 | 12 | 1.4 | C | 非浮NL |
ZX5073 | 65 | MS/SN | 99.0 | 10 | 1.4 | C | 非浮NL |
ZX7004 | 65 | MS/SN | 99.0 | 13 | 1.5 | C | 非浮NL |
ZX8130 | 65 | MS/SN | 99.0 | 16 | 1.5 | C | 非浮NL |
ZX8086 | 65 | MS/SN | 99.0 | 11 | 1.5 | C | 非浮NL |
ZX8088 | 65 | MS/SN | 99.0 | 9 | 1.5 | C | 非浮NL |
ZX8089 | 65 | MS/SN | 99.0 | 8 | 1.5 | C | 非浮NL |
溶 剂 类 型 :MS- 矿 物 油 ,SN- 石 脑 油 。
包装方式:25公斤铁桶包装。
Solvent type:MS-Mineral Spirit,SN-Solvent Naphtha.
Package:25kg-iron drum.
高级银白浆
Sophisticated Silver-White Paste
特性
与银白浆相比,该系列铝银浆的生产工艺更精 细,粒子形状更规则且均匀,粒径分布更集 中。其优越性主要体现在使涂层表面更细腻均 匀,白度优良,亮度提高,遮盖力更强。
典型应用
适用于溶剂系统。
高端工业装饰如电子产品外壳漆、高级塑胶 漆,以及印刷油墨等。
Properties
Produced with special technique and different quality control process,this series of non-eafing aluminium paste has better regularity in particle shape and narrower particle size distribution than Silver-White series, providing improved smoothness,lightness,and hiding power.
Typical Application
For solvent system.
High-end industrial decoration,such as electronic product exterior coatings,plastic coatings,and printing inks.
型 号 Grade | 固 含 量 | 溶剂类别 | 湿法筛网 | 平 均 粒 径 | 比 重 | 铝片形貌 | 浮/非浮 |
Nonvolatile | Solvent | 通 过 率 | Average | Specific | Particle | Leafing |
content %(±2) |
| Screen analysis <45μm(≥%) | partcle size (μm) | gravity (g/cm³) | Shape | Non-leafing |
ZA9160 | 65 | MS/SN | 99.0 | 14 | 1.4 | B | 非浮NL |
ZA9170 | 65 | MS/SN | 99.0 | 12 | 1.4 | B | 非浮NL |
ZA9180 | 70 | MS/SN | 99.0 | 7 | 1.4 | A | 非浮NL |
ZA9190 | 70 | MS/SN | 99.0 | 6 | 1.4 | A | 非浮NL |
ZX31401B | 68 | MS/SN | 99.0 | 14 | 1.4 | B | 非浮NL |
ZX30901B | 68 | MS/SN | 99.0 | 9 | 1.4 | B | 非浮NL |
ZX30701B | 68 | MS/SN | 99.0 | 7 | 1.4 | B | 非浮NL |
溶剂类型: MS- 矿 物 油 ,SN- 石脑油。
包装方式:25公斤铁桶包装。
Solvent type:MS-Mineral Spirit,SN-Solvent Naphtha.
Package:25kg-iron drum.
中粗闪铝银浆 Sparkle Paste
特性
该系列是用高纯度的原材料制作而成的银元形 铝银浆,具有优秀的闪烁度、光亮度和金属效 果 。 其 中 ,ZXH系 列 产 品 具 有 更 高 的 闪 烁 度 。
Properties
This series of non-leafing aluminium paste is silver-dollar type manufactured with high-purity raw material.It offers sparkle effect with outstanding glittering,radiance,and flip-flop.ZXH series of products are more sparkle.
典型应用
适用于溶剂系统 。
一般工业装饰,如机器设备、注塑、办公设备、 玩具与工艺品等的装饰用漆。也可用于汽车漆。
Typical Application
For solvent system.
General industrial decoration:machinery coatings, injection moulding,office equipment,toys and art crafts. Also automotive coatings.
型 号 Grade | 固 含 量 | 溶剂类别 | 湿法筛网 | 平 均 粒 径 | 比 重 | 铝片形貌 | 浮 / 非 浮 |
Nonvolatile content | Solvent | 通 过 率 Screen analysis | Average partcle size | Specific gravity | Particle Shape | Leafing Non-leafing |
%(±2) |
| <45μm(≥%) | (μm) | (g/cm³) |
|
|
ZX2703 | 75 | MS/SN | 99(120mesh) | 59 | 1.6 | B | 非浮NL |
ZX2702 | 75 | MS/SN | 99(120mesh) | 41 | 1.6 | B | 非浮NL |
ZX¹033 | 75 | MS/SN | 98.0 | 33 | 1.6 | B | 非浮NL |
ZX1030 | 75 | MS/SN | 98.0 | 29 | 1.6 | B | 非浮NL |
ZX1497 | 75 | MS/SN | 99.0 | 26 | 1.6 | B | 非浮NL |
ZX1308 | 75 | MS/SN | 99.0 | 23 | 1.6 | B | 非浮NL |
ZXH76120 | 72 | MS/SN | 99(30mesh) | 120 | 1.6 | A | 非浮NL |
ZXH7688 | 72 | MS/SN | 99(80mesh) | 88 | 1.6 | A | 非浮NL |
ZXH7650 | 72 | MS/SN | 99(120mesh) | 50 | 1.6 | A | 非浮NL |
ZXH7640 | 72 | MS/SN | 99(120mesh) | 40 | 1.6 | A | 非浮NL |
ZXH7630 | 72 | MS/SN | 98.0 | 30 | 1.6 | A | 非浮NL |
ZXH7620 | 72 | MS/SN | 99.0 | 20 | 1.6 | A | 非浮NL |
溶 剂 类 型 :MS- 矿 物 油 ,SN- 石 脑 油 。
包装方式:25公斤铁桶包装。
Solvent type:MS-Mineral Spirit,SN-Solvent Naphtha.
Package:25kg-iron drum.
树脂包覆型铝银浆
Resin-Coated Aluminium Paste
特性
使用树脂包覆铝粒子,铝颜料与树脂系统的亲 和力极其优良,超强防酸碱腐蚀,优异的耐候 性,优异的电气绝缘性。树脂含量为浆体重量 的7.5%,厚度为0.5μm, 可以根据用户需要调
整 。
典型应用
适用于溶剂系统 。
高级工业装饰,如手机/家用电器等外壳漆, UV底漆,建筑外墙涂料及卷材涂料。
Properties
Aluminium particles are coated with polymer layer, demonstrating remarkable compatibility between aluminium pigment and vehicle system,distinct anti- corrosion property,excellent weather resistance property, and excelent electrical insulation property.Content of polymer layer is 7.5%of weight of the paste,thickness 0.5μm,which can be customized.
Typical Application
For solvent system.
High-end industrial decoration:mobile and home electrical appliance coatings,UV base coatings.Architecture exterior coatings and coil coatings.
型 号 Grade | 固 含 量 Nonvolatile content %(±2) | 溶剂类别 Solvent | 湿 法 筛 网 通过率 Screen analysis <45μm(≥%) | 平 均 粒 径 Average partcle size (μm) |  铝片形貌 浮 / 非 浮
| 树 脂 包 覆 量 Resin content (%wt) |
Particle Shape | Leafing Non-leafing |
ZC6006 | 45 | MS/SN | 99.0 | 6 | B | 非浮NL | 标准厚度 Standard thickness |
ZC6010 | 50 | MS/SN | 99.0 | 10 | B | 非浮NL | 标准厚度 Standard thickness |
ZC6014 | 50 | MS/SN | 99.0 | 14 | B | 非浮NL | 标准厚度 Standard thickness |
ZC903 | 63 | MS/SN | 99.0 | 34 | B | 非浮NL | 标准厚度 Standard thickness |
ZC905 | 63 | MS/SN | 99.0 | 23 | B | 非浮NL | 标准厚度 Standard thickness |
ZC906 | 55 | MS/SN | 99.0 | 15 | B | 非浮NL | 标准厚度 Standard thickness |
ZC909 | 55 | MS/SN | 99.0 | 10 | B | 非浮NL | 标准厚度 Standard thickness |
ZC921 | 69 | MS/SN | 99.0 | 53 | B | 非浮NL | 厚包覆 Thicker coating |
ZC923 | 64 | MS/SN | 99.0 | 34 | B | 非浮NL | 厚包覆 Thicker coating |
ZC924 | 63 | MS/SN | 99.0 | 30 | B | 非浮NL | 厚包覆 Thicker coating |
ZC925 | 65 | MS/SN | 99.0 | 23 | B | 非浮NL | 厚包覆 Thicker coating |
ZC926 | 55 | MS/SN | 99.0 | 15 | B | 非浮NL | 厚包覆 Thicker coating |
ZC929 | 55 | MS/SN | 99.0 | 10 | B | 非浮NL | 厚包覆 Thicker coating |
ZC9997 | 48 | MS/SN | 99.0 | 8 | A | 非浮NL | 薄包覆 Thin coating |
ZC9999 | 49 | MS/SN | 99.0 | 11 | A | 非浮NL | 薄包覆 Thin coating |
ZCP1008 | 52 | MS/SN | 99.0 | 8 | B | 非浮NL | 标准厚度 Standard thickness |
ZCP1015 | 55 | MS/SN | 99.0 | 18 | B | 非浮NL | 标准厚度 Standard thickness |
标准厚度:约7.5;厚包覆:约12;薄包覆:约3.5。
Standard thickness:About 7.5%; Thicker coating:About 12%; Thin coating:About 3.5%.
溶 剂 类 型 :MS- 矿 物 油 ,SN- 石 脑 油 。
包装方式:15公斤铁桶包装。
树脂包覆量 : 占浆体重量的百分比 。
Solvent type:MS -Mineral Spirit,SN -Solvent Naphtha.
Package:15kg-iron drum.
Resin content:percentage by weight of the paste.
水性铝银浆
Water-Borne Aluminium Paste
特性
经二氧化硅表面包覆的产品能分散于水中,具 有良好的耐水性,极低气体释放和优异的耐候 性 。
Properties
The silica-coated products can be dispersed in water, showing high compatibility with water,minimum gassing, and good weather resistance.
经过磷酸酯钝化处理的产品能很好地分散于水 中,具有良好的印刷转移性,同时耐水性好, 粒径分布窄 , 遮盖力佳 , 金属感优异 。
The phosphate passivated water borne products can be
dispersed in water very well.This series of products have
charicteristics of good printing transferability,narrow
particle size distribution,brilliant hiding power,and
excellent metallic effect.
典 型 应 用
适用于水性涂料系统和水性油墨 。
Typical Application
For water-borne paint system and aqueous printing inks.
型 号 Grade | 固 含 量 Nonvolatile content %(±2) | 溶剂类别 Solvent | 湿法筛网 通 过 率 Screen analysis <45μm(≥%) | 平 均 粒 径 Average partcle size (μm) | 铝片形貌 Particle Shape | 浮 / 非 浮 Leafing Non-leafing | 表面处理 Surface Treatment | 包装规格 Packing Specifications |
ZW2214 | 60 | 正丙醇 1-Propanol | 99.0 | 39 | A | 非浮NL | SiO2 | 15KG |
ZW1066 | 60 | 正丙醇 1-Propanol | 99.0 | 20 | A | 非浮NL | SiO2 | 15KG |
ZW1801 | 52 | 正丙醇 1-Propanol | 99.0 | 13 | A | 非浮NL | SiO2 | 15KG |
ZW9090 | 48 | 正丙醇 1-Propanol | 99.0 | 8 | A | 非浮NL | SiO2 | 15KG |
ZW5020 | 58 | 丙二醇甲醚 PM | 99.0 | 20 | A | 非浮NL | SiO2 | 15KG |
ZW5014 | 55 | 丙二醇甲醚 PM | 99.0 | 14 | A | 非浮NL | SiO2 | 15KG |
ZW5010 | 50 | 丙二醇甲醚 PM | 99.0 | 10 | A | 非浮NL | SiO2 | 15KG |
ZW5006 | 48 | 丙二醇甲醚 PM | 99.0 | 6 | A | 非浮NL | SiO2 | 15KG |
ZW6911 | 62 | 正丙醇 1-Propanol | 99.0 | 16 | A | 非浮NL | SiO2+丙烯酸树脂 SiO2+Acrylic Resin | 25KG |
ZW6908 | 60 | 正丙醇 1-Propanol | 99.0 | 11 | A | 非浮NL | SiO2+丙烯酸树脂 SiO2+Acrylic Resin | 25KG |
ZW6905 | 60 | 正丙醇 1-Propanol | 99.0 | 8 | A | 非浮NL | SiOz+丙烯酸树脂 SiO2+Acrylic Re sin | 25KG |
ZWD727 | 65 | 丙二醇甲醚 PM | 99.0 | 27 | A | 非浮NL | 磷酸酯 Phosphate | 20KG |
ZWD718 | 60 | 丙二醇甲醚 PM | 99.0 | 18 | A | 非浮NL | 磷酸酯 Phosphate | 20KG |
ZWD790 | 55 | 丙二醇甲醚 PM | 99.0 | 12 | A | 非浮NL | 磷酸酯 Phosphate | 20KG |
ZWF1305 | 60 | 正丙醇 1-Propanol | 99.0 | 25 | A | 浮L | SiO2 | 20KG |
ZWF1801 | 60 | 正丙醇 1-Propanol | 99.0 | 13 | A | 浮L | SiO2 | 20KG |
ZWF9090 | 55 | 正丙醇 1-Propanol | 99.0 | 8 | A | 浮L | SiO2 | 20KG |
