网站主页CAS数据库列表 106-95-6更多图谱3-溴丙烯(106-95-6)Raman光谱

3-溴丙烯

产品名称 3-溴丙烯

CAS号106-95-6

分子式C3H5Br

分子量120.98

展开


  • Mass

    MS-NW-3528
    3-bromo-1-propene
    C3H5Br              (Mass of molecular ion:    120)


       Source Temperature: 290 °C
       Sample Temperature: 180 °C
       Reservoir, 75 eV


          15.0       2.8
          26.0       2.1
          27.0       2.8
          37.0       2.9
          38.0       5.7
          39.0      46.7
          40.0       5.2
          41.0     100.0
          42.0       3.5
         120.0       8.0
         122.0       8.2


parameter in CDCl3

90 MHz in CDCl3


  • 1H NMR 300 MHz
    C3 H5 Br 10 vol% in CCl4
    3-bromo-1-propene
    ChemicalStructure
        Parameter     ppm  Hz
    D(A) 5.994 D(B) 5.113 D(C) 5.286 D(D) 3.873 J(A,B) 9.97 J(A,C) 16.79 J(A,D) 7.27 J(B,C) 1.20 J(B,D) -0.59 J(C,D) -1.21 BOTHNER-BY,A.A. & GUENTHER,H. DISC.FAR.SOC. 34, 127 (1962)

         Hz     ppm     Int.


       1819.29   6.064    130
       1812.03   6.040    264
       1809.37   6.031    146
       1804.79   6.016    146
       1802.14   6.007    356
       1795.21   5.984    377
       1792.57   5.975    174
       1787.99   5.960    166
       1785.33   5.951    332
       1778.06   5.927    172
       1595.66   5.319    211
       1594.47   5.315    534
       1593.28   5.311    544
       1592.10   5.307    221
       1578.86   5.263    182
       1577.70   5.259    457
       1576.49   5.255    463
       1575.32   5.251    190
       1539.34   5.131    483
       1538.80   5.129    506
       1538.23   5.127    466
       1529.39   5.098    445
       1528.85   5.096    469
       1528.29   5.094    434
       1165.81   3.886   1000
       1165.22   3.884    999
       1158.56   3.862    969
       1157.96   3.860    966



  • 1H NMR 89.56 MHz
    C3 H5 Br 0.04 ml : 0.5 ml CDCl3
    3-bromo-1-propene
    ChemicalStructure
        Assign.     Shift(ppm)
    A 6.015 B 5.30 C 5.15 D 3.934 J(A,B)=16.8HZ. J(A,C)=9.7HZ. J(A,D)=7.2HZ.

         Hz     ppm     Int.


        562.13   6.277    113
        554.88   6.196    198
        552.38   6.168    140
        547.75   6.117    126
        545.25   6.089    371
        538.06   6.008    448
        535.56   5.980    232
        530.94   5.929    210
        528.31   5.899    384
        521.25   5.821    267
        485.13   5.417    201
        484.06   5.405    468
        482.69   5.390    608
        481.63   5.378    296
        468.31   5.230    143
        467.25   5.218    338
        465.81   5.202    810
        464.88   5.191    512
        464.44   5.186    507
        456.06   5.093    384
        455.25   5.084    309
        454.69   5.077    392
        356.50   3.981    903
        356.13   3.977   1000
        355.56   3.971    964
        355.06   3.965    868
        349.38   3.902    792
        348.88   3.896    895
        348.38   3.890    914
        347.81   3.884    811


in CDCl3



liquid film





REACTION WITH NA AT 77K
