桃金娘烯醛

产品名称 桃金娘烯醛

CAS号18486-69-6

分子式C10H14O

分子量150.22


  • Mass

    MS-NW-7496
    (1R)-(-)-myrtenal
    C10H14O             (Mass of molecular ion:    150)


       Source Temperature: 260 °C
       Sample Temperature: 170 °C
       Reservoir, 75 eV


          15.0       1.1
          18.0       1.0
          26.0       1.0
          27.0      19.4
          28.0       2.8
          29.0      10.4
          38.0       2.0
          39.0      27.0
          40.0       4.5
          41.0      35.3
          42.0       2.4
          43.0      16.6
          50.0       4.2
          51.0      12.1
          52.0       5.4
          53.0      17.3
          54.0       2.7
          55.0       9.5
          56.0       1.7
          57.0       1.2
          59.0       3.5
          62.0       1.1
          63.0       3.6
          64.0       1.0
          65.0      10.1
          66.0      14.2
          67.0      12.7
          68.0       4.7
          69.0       4.7
          75.0       1.0
          77.0      35.3
          78.0       8.2
          79.0     100.0
          80.0      11.7
          81.0       8.3
          82.0       2.3
          83.0       2.5
          90.0       1.6
          91.0      32.6
          92.0       7.7
          93.0      13.6
          94.0      12.4
          95.0       6.9
          96.0       2.3
         103.0       2.8
         104.0       1.3
         105.0      24.9
         106.0      32.1
         107.0      67.2
         108.0      37.9
         109.0       7.3
         115.0       2.9
         116.0       1.0
         117.0       8.3
         118.0       1.1
         119.0       2.7
         120.0       1.0
         121.0       7.8
         122.0       3.0
         123.0       1.1
         131.0       1.6
         132.0       1.7
         133.0       1.4
         135.0      14.7
         136.0       1.7
         149.0       1.3
         150.0       2.8


400 MHz in CDCl3


  • 1H NMR 399.65 MHz
    C10 H14 O 0.05 ml : 0.5 ml CDCl3
    (1R)-(-)-myrtenal
    ChemicalStructure
        Assign.     Shift(ppm)
    A 9.443 B 6.726 C 2.865 D 2.585 E 2.560 F 2.490 J 2.194 K *1 1.341 L 1.057 M *1 0.746

         Hz     ppm     Int.


       3774.17   9.444    458
       2692.99   6.739     55
       2691.53   6.735    103
       2689.82   6.731    135
       2688.23   6.727    192
       2686.77   6.723    145
       2684.94   6.719    108
       2683.59   6.715     62
       1151.73   2.882     70
       1150.27   2.879     77
       1146.00   2.868    130
       1144.65   2.865    142
       1140.38   2.854     77
       1139.04   2.851     83
       1036.25   2.593    101
       1033.08   2.585    182
       1030.03   2.578    109
       1026.12   2.568    126
       1023.19   2.561    200
       1020.26   2.553    132
       1004.88   2.515     79
        999.39   2.501    133
        999.02   2.500    134
        995.61   2.492     76
        993.53   2.486     79
        989.87   2.477    127
        984.25   2.463     73
        884.52   2.214     31
        883.30   2.211     47
        881.96   2.207     50
        880.37   2.203     69
        878.91   2.200     69
        877.44   2.196     86
        875.98   2.192     87
        874.63   2.189     70
        873.17   2.185     66
        871.70   2.182     48
        870.12   2.178     44
        536.13   1.342    949
        528.44   1.323     31
        427.00   1.069    243
        417.85   1.046    239
        298.10   0.746   1000


in CDCl3



liquid film
