N-苯基马来酰亚胺

产品名称 N-苯基马来酰亚胺

CAS号941-69-5

分子式C10H7NO2

分子量173.17

展开


  • Mass

    MS-NW-7233
    N-phenylmaleimide
    C10H7NO2            (Mass of molecular ion:    173)


       Source Temperature: 210 °C
       Sample Temperature: 190 °C
       Reservoir, 75 eV


          26.0      14.2
          27.0       2.1
          28.0       1.3
          37.0       2.1
          38.0       5.2
          39.0       6.5
          40.0       1.3
          41.0       1.7
          50.0       3.6
          51.0       6.9
          52.0       3.0
          53.0       4.9
          54.0      30.6
          55.0       1.8
          58.5       3.3
          62.0       1.8
          63.0       6.7
          64.0      11.5
          65.0       4.5
          72.5       2.6
          74.0       1.2
          75.0       1.1
          76.0       1.9
          77.0       9.7
          78.0       1.0
          80.0       3.7
          82.0       2.4
          86.5       2.3
          89.0       1.9
          90.0       6.0
          91.0      12.4
          92.0       1.6
          93.0       4.0
          94.0       2.2
         103.0      17.7
         104.0       7.8
         116.0       1.7
         117.0      13.7
         118.0       1.7
         119.0       8.5
         120.0       1.2
         128.0       3.3
         129.0      22.3
         130.0       2.4
         131.0       1.4
         144.0       4.0
         145.0       6.9
         146.0       1.0
         172.0       2.9
         173.0     100.0
         174.0      11.5
         175.0       1.2


400 MHz in CDCl3

90 MHz in CDCl3


  • 1H NMR 399.65 MHz
    C10 H7 N O2 0.026 g : 0.5 ml CDCl3
    N-phenylmaleimide
    ChemicalStructure
        Assign.     Shift(ppm)
    A 7.465 B 7.36 C 7.34 D 6.836 90MHZ : HSP-04-943

         Hz     ppm     Int.


       2994.51   7.493     35
       2993.16   7.490     69
       2992.43   7.488     87
       2990.60   7.484     46
       2986.57   7.473     89
       2984.99   7.470    213
       2983.89   7.467    120
       2978.76   7.454     95
       2977.17   7.450    178
       2974.85   7.444     36
       2953.49   7.391     57
       2952.15   7.387     94
       2950.93   7.384     69
       2946.66   7.374     54
       2944.82   7.369    120
       2942.63   7.364     49
       2937.74   7.351    251
       2936.40   7.348    253
       2934.20   7.342     62
       2930.05   7.332    114
       2929.20   7.330    181
       2927.98   7.327    142
       2731.93   6.836   1000



  • 1H NMR 89.56 MHz
    C10 H7 N O2 0.041 g : 0.5 ml CDCl3
    N-phenylmaleimide
    ChemicalStructure
        Assign.     Shift(ppm)
    A 7.58 to 7.230 B 6.806 400MHZ : HSP-44-097

         Hz     ppm     Int.


        672.38   7.508     31
        670.75   7.490     38
        669.94   7.481     35
        667.69   7.456    104
        666.25   7.440     83
        664.25   7.417    123
        662.75   7.401    319
        661.25   7.384    199
        659.56   7.365    303
        658.94   7.358    219
        657.06   7.337     91
        654.75   7.311     57
        653.63   7.299     73
        652.63   7.288     43
        651.13   7.271     50
        650.56   7.264     37
        649.50   7.253     44
        609.63   6.807   1000


in CDCl3



KBr disc



nujol mull
